Installation Instructions

• If applicable, remove exsisting coupler and bolts, discard old bolts and nuts.
• Determine desired mouting height of trailer coupler and slide the supplied bolts (2) though the Kraken bolt plate and the C-channle coupler assembly (not supplied).
• On the opposite side attach the Kraken Lock box in desired position over bolt treads.
• Install the supplied flat washers (2) then tread the supplied lock nuts (2) onto the bolt ends.
• Using a 15/16 socket, tighten locking nuts to at least 80 ft. lbs. of torque (120 ft. lbs. maximum torque)
• Close Kraken Lock box, turn key to engage lock mechanism and remove key (key only releases when box is in locked position)
• Record your key# and keep in a safe place!
• After first 50 miles of trailer use re-check lock nut torque and then periodically thereafter and during yearly DOT inspections.

  1. Remove one of the jam nut/bolt where the Kraken lock is going to be mounted. (Some couplers may only have one jam bolt)

2. Install supplied set screw into gooseneck bolt hole and tighten to 80ft lbs with a 3/8 Allen wrench (not supplied)

3. Install one of the supplied flat washers over set screw and then slip the Kraken Lock box over the set screw and washer using the middle hole in lock box. (Can use one of the other holes in lock box if desired)

4. Install 2nd supplied flat washer over set screw on inside of Kraken Lock box, then install the supplied lock ring washer.

5. Install supplied jam nut and tighten nut to 100ft lbs.

6. Close Kraken Lock box and rotate key to lock position to remove key. (Key only releases when in locked position)

7. Record your key# and keep in a safe place.

8. Recheck jam nut tightness after 1st100 miles of towing and then periodically thereafter.
